| Type | Description | ||
|---|---|---|---|
| Rating | Catalog | Topology | Buck |
| Iout (max) (A) | 2 | Vin (max) (V) | 5.5 |
| Vin (min) (V) | 2.85 | Vout (max) (V) | 3.3 |
| Vout (min) (V) | 0.8 | Features | Enable, Synchronous Rectification, Tracking |
| Control mode | Voltage mode | Switching frequency (min) (kHz) | 500 |
| Switching frequency (max) (kHz) | 1500 | Operating temperature range (°C) | -40 to 125 |
| Iq (typ) (µA) | 850 | Duty cycle (max) (%) | 100 |
| Type | Converter | Package | HTSSOP (PWP) |
| Pins | 14 | Size | 32 mm² 5 x 6.4 |
| REACH Status | Yes | RoHS Status | RoHS Compliant |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LM2852XMXAX-1.2/NOPB is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard HTSSOP (PWP) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LM2852XMXAX-1.2/NOPB datasheet above.
Electronic component spot-market pricing for LM2852XMXAX-1.2/NOPB fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LM2852XMXAX-1.2/NOPB depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
