| Type | Description | ||
|---|---|---|---|
| RoHS Status | RoHS Compliant | Part Life Cycle Code | Active |
| Reach Compliance Code | compliant | ECCN Code | EAR99 |
| HTS Code | 8541.10.00.70 | Application | GENERAL PURPOSE |
| Configuration | SINGLE | Diode Element Material | SILICON |
| Diode Type | RECTIFIER DIODE | JESD-30 Code | R-PDSO-G2 |
| JESD-609 Code | e3 | Moisture Sensitivity Level | 1 |
| Number of Elements | 1 | Number of Phases | 1 |
| Number of Terminals | 2 | Operating Temperature-Max | 150 °C |
| Operating Temperature-Min | -40 °C | Output Current-Max | 0.3 A |
| Package Body Material | PLASTIC/EPOXY | Package Shape | RECTANGULAR |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
BAT54JFILM-HQ is an authentic electronic component manufactured by STMicroelectronics, categorized under Diodes & Rectifiers. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official BAT54JFILM-HQ datasheet above.
Electronic component spot-market pricing for BAT54JFILM-HQ fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for BAT54JFILM-HQ depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
