| Type | Description | ||
|---|---|---|---|
| Pkg. Type | TDFN | Carrier Type | Reel |
| Country of Assembly | MALAYSIA | Country of Wafer Fabrication | TAIWAN |
| Control Type | Current Mode | Duty Cycle (%) | 100 - 100 |
| IQ [Rail 1] (µA) | 2200 | Input Voltage (Max) (V) | 6 |
| Input Voltage (Max) [Rail 1] | 6 | Input Voltage (Max) [Rail 2] | 6 |
| Input Voltage (Min) (V) | 1.8 | Input Voltage (Min) [Rail 1] (V) | 1.8 |
| Lead Count (#) | 22 | Length (mm) | 6 |
| MOQ | 6000 | Moisture Sensitivity Level (MSL) | 3 |
| Output Current (Max) [Rail 1] (A) | 0.5 | Output Current (Max) [Rail 2] (A) | 0.5 |
| Output Voltage (Max) (V) | 5.5 | Output Voltage (Max) [Rail 1] (V) | 5.5 |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
RAA2124214GNP#HA0 is an authentic electronic component manufactured by Renesas, categorized under Power Management ICs. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official RAA2124214GNP#HA0 datasheet above.
Electronic component spot-market pricing for RAA2124214GNP#HA0 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for RAA2124214GNP#HA0 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
