  5. /NGTB20N60L2TF1G
NGTB20N60L2TF1G thumbnail 1
onsemi

NGTB20N60L2TF1G

Category
Transistors
Manufacturer
onsemiDetails
Datasheet
Description
IGBT, N-Channel 600V, 20A, VCE(sat);1.45V TO-3PF-3L with Low VF Switching Diode
Similar Products
—
Quality Control
Authentic & Traceable
Shipping (In-stock)
1-3 business days
Quote Response
Within 24 Hours
Stock Status5900
QuantityNGTB20N60L2TF1G
Country

Get Tiered Pricing (Submit RFQ)

Specification
Product Details
Key Features
Applications
Documentation
TypeDescriptionTypeDescription
Container TypeTUBEIC Max (A)20
Case Outline340AHMSL Temp (°C)0
V(BR)CES Typ (V)600VF Typ (V)1.5
Gate Charge Typ (nC)84Trr Typ (ns)70
Container Qty.30VCE(sat) Typ (V)1.45
PD Max (W)64Co-Packaged DiodeYes
Package TypeTO-3PF-3L
