| Type | Description | ||
|---|---|---|---|
| Coss Typ (pF) | 30 | Vgs (V) | 9 |
| Qg Typ @ VGS = 10 V (nC) | 2.9 | Channel Polarity | N-Channel |
| Silicon Family | PowerTrench® T1 | Configuration | Single |
| OPN in older Technology | 0 | Wide SOA Mosfets | 0 |
| RDS(on) Max @ VGS = 2.5 V (mΩ) | 147 | V(BR)DSS Min (V) | 20 |
| Vgs(th) Max (V) | 0.9 | ID Max (A) | 2 |
| RDS(on) Max @ VGS = 4.5 V (mΩ) | 104 | MSL Type | 1 |
| Qgd Typ @ VGS = 4.5 V (nC) | 0.53 | Ciss Typ (pF) | 175 |
| Container Qty. | 3000 | Package Name | MCPH-3 |
| Gate Level | Logic | Package Type | SC-70FL / MCPH-3 |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
MCH3481-TL-W is an authentic electronic component manufactured by onsemi, categorized under Transistors. It is supplied in the standard MCPH-3 package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official MCH3481-TL-W datasheet above.
Electronic component spot-market pricing for MCH3481-TL-W fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for MCH3481-TL-W depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
