| Type | Description | ||
|---|---|---|---|
| Package | MSOP-8 | Voltage - Supply | -5.5V~5.5V |
| Gain Bandwidth Product | 500kHz | Vos - Input Offset Voltage | 5uV |
| Input Offset Voltage Drift(Vos TC) | 25nV/℃ | Ib - Input Bias Current | 3pA |
| Maximum Power Supply Range (Vdd-Vss) | 11V | Slew Rate | 0.5V/us |
| Number of Channels | 2 | Quiescent Current(Iq) | 150uA |
| Common Mode Rejection Ratio(CMRR) | 130dB | Operating Temperature | -40℃~+85℃ |
| Rail To Rail | Rail-to-Rail Output | Input Offset Current(Ios) | 150pA |
| CNHTS | 8542339000 | USHTS | 8542330001 |
| TARIC | 8542339000 | CAHTS | 8542330000 |
| BRHTS | 85423390 | INHTS | 85423300 |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LTC2055HVIMS8#PBF is an authentic electronic component manufactured by Analog Devices, categorized under Amplifier ICs. It is supplied in the standard MSOP-8 package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LTC2055HVIMS8#PBF datasheet above.
Electronic component spot-market pricing for LTC2055HVIMS8#PBF fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LTC2055HVIMS8#PBF depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
