| Type | Description | ||
|---|---|---|---|
| Processor supplier | Generic | Processor name | Generic |
| Product type | Processor and FPGA | Regulated outputs (#) | 4 |
| Step-down DC/DC converter | 4 | Step-up DC/DC converter | 0 |
| LDO | 0 | Vin (min) (V) | 2.5 |
| Vin (max) (V) | 5.5 | Vout (min) (V) | 0.5 |
| Vout (max) (V) | 3.36 | Iout (max) (A) | 4 |
| Configurability | Factory programmable, Software configurable | Features | Adjustable current limit, Dynamic voltage scaling, Enable, I2C, Light-load efficiency, Multiple outputs, Output discharge, Phase interleaving, Power good, Remote sense, Synchronous rectification |
| Rating | Catalog | Operating temperature range (°C) | -40 to 105 |
| Step-down DC/DC controller | 0 | Step-up DC/DC controller | 0 |
| Iq (typ) (mA) | 0.006 | Switching frequency (max) (kHz) | 3000 |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LP8758-EA is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard DSBGA (YFF) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LP8758-EA datasheet above.
Electronic component spot-market pricing for LP8758-EA fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LP8758-EA depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
