| Type | Description | ||
|---|---|---|---|
| Rating | Catalog | Topology | Buck |
| Iout (max) (A) | 0.6 | Vin (max) (V) | 60 |
| Vin (min) (V) | 4.2 | Vout (max) (V) | 57 |
| Vout (min) (V) | 1 | Features | Enable, Light Load Efficiency, Over Current Protection, Power good, Pre-Bias Start-Up, Synchronous Rectification, Wettable flanks package |
| EMI features | Low parasitic Hotrod packaging, Spread Spectrum | Control mode | current mode |
| Switching frequency (min) (kHz) | 1000 | Switching frequency (max) (kHz) | 2100 |
| TI functional safety category | Functional Safety-Capable | Operating temperature range (°C) | -40 to 150 |
| Iq (typ) (µA) | 23 | Duty cycle (max) (%) | 98 |
| Type | Converter | Package | VQFN-HR (RNX) |
| Pins | 12 | Size | 6 mm² 3 x 2 |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LMR36006BRNXR is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard VQFN-HR (RNX) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LMR36006BRNXR datasheet above.
Electronic component spot-market pricing for LMR36006BRNXR fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LMR36006BRNXR depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
