| Type | Description | ||
|---|---|---|---|
| Vin (max) (V) | 75 | Vin (min) (V) | 6 |
| FET | External single FET | Device type | ORing controller |
| Number of channels | 1 | Rating | Catalog |
| Features | FET test, Linear control, Reverse current blocking | Imax (A) | 250 |
| Iq (typ) (mA) | 0.4 | Iq (max) (mA) | 0.72 |
| IGate source (typ) (µA) | 32 | IGate source (max) (µA) | 45 |
| IGate sink (typ) (mA) | 2.8 | IGate pulsed (typ) (A) | 2.8 |
| Operating temperature range (°C) | -40 to 125 | VSense reverse (typ) (mV) | -41, -28 |
| Design support | EVM, Reference Design, Simulation Model | VGS (max) (V) | 14.7 |
| Shutdown current (ISD) (mA) (A) | 0.1 | Product type | ORing controller |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LM5050-2 is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard SOT-23-THN (DDC) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LM5050-2 datasheet above.
Electronic component spot-market pricing for LM5050-2 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LM5050-2 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
