| Type | Description | ||
|---|---|---|---|
| Rating | Catalog | Vin (max) (V) | 26 |
| Vin (min) (V) | 6 | Iout (max) (A) | 1 |
| Output options | Fixed Output | Vout (max) (V) | 15 |
| Vout (min) (V) | 5 | Fixed output options (V) | 5, 8, 9, 10, 12, 15 |
| Noise (µVrms) | 150 | PSRR at 100 KHz (dB) | 48 |
| Iq (typ) (mA) | 10 | Thermal resistance θJA (°C/W) | 23, 41, 59 |
| Load capacitance (min) (µF) | 22 | Regulated outputs (#) | 1 |
| Accuracy (%) | 2 | Dropout voltage (Vdo) (typ) (mV) | 500 |
| Operating temperature range (°C) | -40 to 125 | Package | TO-263 (KTT) |
| Pins | 3 | Size | 154.8384 mm² (10.16 mm × 15.24 mm) |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LM2940-N is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard TO-263 (KTT) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LM2940-N datasheet above.
Electronic component spot-market pricing for LM2940-N fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LM2940-N depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
