| Type | Description | ||
|---|---|---|---|
| Rating | Catalog | Number of series cells | 1 |
| Cell chemistry | Li-Ion/Li-Polymer, Lithium Phosphate/LiFePO4 | Charge current (max) (A) | 0.3 |
| Features | BAT temp thermistor monitoring (JEITA profile), IC thermal regulation, Input OVP, Integrated LDO, Integrated buck converter, Power Path, VINDPM (Input voltage threshold to maximize adaptor power) | Vin (min) (V) | 3.4 |
| Vin (max) (V) | 5.5 | Absolute max Vin (max) (V) | 20 |
| Control topology | Linear | Battery charge voltage (min) (V) | 3.6 |
| Battery charge voltage (max) (V) | 4.65 | Control interface | I2C |
| Operating temperature range (°C) | -40 to 85 | Package | DSBGA (YFP) |
| Pins | 25 | Size | 6.75999999999999792000000000000016 mm² (— mm × — mm) |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
BQ25120F3A is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard DSBGA (YFP) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official BQ25120F3A datasheet above.
Electronic component spot-market pricing for BQ25120F3A fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for BQ25120F3A depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
