| Type | Description | ||
|---|---|---|---|
| Carrier Type | Bulk (Tray) | Family Name | RL78 |
| Series Name | RL78/G1x | Group Name | G13 |
| CPU Architecture | RL78 | Main CPU | RL78-S2 |
| Sub CPU | No | Floating Point Unit | No |
| Bit Length | 16 | Program Memory (KB) | 256 |
| Data Flash (KB) | 0 | RAM (KB) | 20 |
| ECC SRAM | No | Lead Count (#) | 128 |
| Pitch (mm) | 0.5 | Pkg. Dimensions (mm) | 20 x 14 x 1.6 |
| Number of Supply Voltage(s) (#) | 1 | Supply Voltage (V) | 1.6 - 5.5 |
| I/O Ports | 120 | DMAC or DTC | DMAC |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
R5F101SJDFB#30 is an authentic electronic component manufactured by Renesas, categorized under Microcontrollers - MCU. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official R5F101SJDFB#30 datasheet above.
Electronic component spot-market pricing for R5F101SJDFB#30 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for R5F101SJDFB#30 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
