| Type | Description | ||
|---|---|---|---|
| Lead Count (#) | 32 | Carrier Type | Reel |
| Moisture Sensitivity Level (MSL) | 3 | Temp. Range (°C) | 0 to +85°C, -40 to +100°C |
| Audible Noise | No | Automatic Power Source Selection | Yes |
| Automatic Trickle Charge (Typical) | Set by user | Battery Charge Voltage | 2-4 cell battery, 16mV step |
| Battery Charge Voltage Adjustment | 16mV steps | Battery Chemistry | Multi-Cell Li+/Polymer |
| Battery Leakage Current (Max) | 245 µA | Charge Current Limit Accuracy | ±2 |
| Charging Voltage Accuracy (Max) (±%) | 0.75 | DC Adapter Detection | Yes |
| Duty Cycle (%) | 100 - 100 | Input Current Limit Accuracy (% (±)) | 2 |
| Input Voltage (Max) (V) | 25 | Input Voltage (Min) (V) | 4.75 |
| Input Voltage Range (V) | 4.75 - 25 | Lead Compliant | No |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
ISL95522 is an authentic electronic component manufactured by Renesas, categorized under Power Management ICs. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official ISL95522 datasheet above.
Electronic component spot-market pricing for ISL95522 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for ISL95522 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
