| Type | Description | ||
|---|---|---|---|
| Copper Support | No | DownstreamPorts | 64 |
| Port Speed | 10/100/1000/2500Mbps 5/10Gbps | Fiber Support | 100FX 1000X SFI |
| IEEE 1588 | No | InterfaceUpStream | SGMII QSGMII USGMII USXGMII XFI |
| LinkMDCableDiag | No | Managed | Yes |
| OpVoltage | 0.9 | Static MAC Address | 32768 |
| Supply Voltages | 0.9 | Temp Range Min (°C) | -40 |
| Temp Range Max (°C) | 125 (Junction) | Digital I/O Voltage | 0.9/1.5/1.8/3.3 |
| WakeonLAN | No | Lead Count (Pins) | 888 |
| Package Type | FCBGA | Temperature Range | 0 to 105 junction |
| Packing Media | TRAY | 5K Pricing | $66.04 |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
VSC7546-V/5CC is an authentic electronic component manufactured by Microchip, categorized under Communication & Networking ICs. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official VSC7546-V/5CC datasheet above.
Electronic component spot-market pricing for VSC7546-V/5CC fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for VSC7546-V/5CC depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
