| Type | Description | ||
|---|---|---|---|
| CPU | Cortex-M4 | I2C | 4 |
| CPU Speed Max MHz (megahertz) | 48 | Operation Voltage Max.(V) | 3.6 |
| Operation Voltage Min.(V) | 1.68 | Internal Oscillator | 80Mhz, 2,4,8Mhz , 32Khz, 115Khz |
| Part Family | ATSAM4LC4B | QSPI | 0 |
| Segmented LCD (# of segments) | 92 | U(S)ART | 4 -UART |
| Program Memory Size (KB) | 256 | Pincount | 64 |
| Crypto Engine | Yes | TempRange Min | -40 |
| TempRange Max | 85 | Lead Count (Pins) | 64 |
| Package Type | VQFN | Temperature Range | -40C to +85C |
| Packing Media | TRAY | 5K Pricing | $5.41 |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
ATSAM4LC4BA-MU is an authentic electronic component manufactured by Microchip, categorized under Microcontrollers - MCU. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official ATSAM4LC4BA-MU datasheet above.
Electronic component spot-market pricing for ATSAM4LC4BA-MU fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for ATSAM4LC4BA-MU depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
