| Type | Description | ||
|---|---|---|---|
| Package | TSOT-23-5 | Vos - Input Offset Voltage | 1.5mV |
| Ib - Input Bias Current | 8uA | Slew Rate | 1.5V/ns |
| Quiescent Current(Iq) | 6.5mA | Common Mode Rejection Ratio(CMRR) | 85dB |
| Operating Temperature | 0℃~+70℃ | Output Current | 50mA |
| Voltage - Supply | -5.5V~5.5V;5V | Gain Bandwidth Product | 220MHz |
| Input Offset Voltage Drift(Vos TC) | 10uV/℃ | Maximum Power Supply Range (Vdd-Vss) | 11V |
| Number of Channels | 1 | Input Offset Current(Ios) | 800nA |
| Noise density(eN) | 6nV/√Hz@10kHz | CNHTS | 8542339000 |
| USHTS | 8542330001 | TARIC | 8542339000 |
| CAHTS | 8542330000 | BRHTS | 85423390 |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LT1815CS5#TRMPBF is an authentic electronic component manufactured by Analog Devices, categorized under Amplifier ICs. It is supplied in the standard TSOT-23-5 package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LT1815CS5#TRMPBF datasheet above.
Electronic component spot-market pricing for LT1815CS5#TRMPBF fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LT1815CS5#TRMPBF depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
