| Type | Description | ||
|---|---|---|---|
| Rating | Automotive | Vin (max) (V) | 40 |
| Vin (min) (V) | 3 | Iout (max) (A) | 0.3 |
| Output options | Fixed Output | Vout (max) (V) | 5 |
| Vout (min) (V) | 3.3 | Fixed output options (V) | 2.5, 3.3, 5 |
| Noise (µVrms) | 450 | PSRR at 100 KHz (dB) | 25 |
| Iq (typ) (mA) | 0.003 | Features | AEC-Q100 Grade 0, Enable |
| Thermal resistance θJA (°C/W) | 31.1, 52, 63.9, 72.8 | TI functional safety category | Functional Safety-Capable |
| Load capacitance (min) (µF) | 1 | Regulated outputs (#) | 1 |
| Accuracy (%) | 2 | Dropout voltage (Vdo) (typ) (mV) | 400 |
| Operating temperature range (°C) | -40 to 165 | Package | HTSSOP (PWP) |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
TPS7B8250QDGNRQ1 is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard HTSSOP (PWP) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official TPS7B8250QDGNRQ1 datasheet above.
Electronic component spot-market pricing for TPS7B8250QDGNRQ1 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for TPS7B8250QDGNRQ1 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
