| Type | Description | ||
|---|---|---|---|
| Rating | Automotive | Vin (max) (V) | 6 |
| Vin (min) (V) | 1.65 | Iout (max) (A) | 0.3 |
| Output options | Adjustable Output, Fixed Output | Vout (max) (V) | 5.5 |
| Vout (min) (V) | 0.75 | Fixed output options (V) | 0.75, 0.8, 0.85, 1, 1.05, 1.1, 1.2, 1.5, 1.7, 1.8, 2.5, 2.8, 2.9, 3, 3.3, 5 |
| Noise (µVrms) | 30 | PSRR at 100 KHz (dB) | 45 |
| Iq (typ) (mA) | 0.025 | Features | Enable, Wettable flanks package |
| Thermal resistance θJA (°C/W) | 61.8, 184.3 | TI functional safety category | Functional Safety-Capable |
| Load capacitance (min) (µF) | 1 | Regulated outputs (#) | 1 |
| Accuracy (%) | 0.5 | Dropout voltage (Vdo) (typ) (mV) | 115 |
| Operating temperature range (°C) | -40 to 150 | Package | VSON (DRB) |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
TPS784-Q1 is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard VSON (DRB) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official TPS784-Q1 datasheet above.
Electronic component spot-market pricing for TPS784-Q1 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for TPS784-Q1 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
