| Type | Description | ||
|---|---|---|---|
| Number of channels | 2 | Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 30 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 3 | Rail-to-rail | In to V- |
| GBW (typ) (MHz) | 0.7 | Slew rate (typ) (V/µs) | 0.3 |
| Vos (offset voltage at 25°C) (max) (mV) | 3 | Iq per channel (typ) (mA) | 0.35 |
| Vn at 1 kHz (typ) (nV√Hz) | 40 | Rating | Catalog |
| Operating temperature range (°C) | 0 to 70 | Offset drift (typ) (µV/°C) | 7 |
| Features | Standard Amps | Input bias current (max) (pA) | 100000 |
| CMRR (typ) (dB) | 80 | Iout (typ) (A) | 0.03 |
| Architecture | Bipolar | Input common mode headroom (to negative supply) (typ) (V) | 0 |
| Input common mode headroom (to positive supply) (typ) (V) | -1.5 | Output swing headroom (to negative supply) (typ) (V) | 0.005 |
YG GROUP supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
LM358A is an authentic electronic component manufactured by Texas Instruments, categorized under Amplifier ICs. It is supplied in the standard TSSOP (PW) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official LM358A datasheet above.
Electronic component spot-market pricing for LM358A fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for LM358A depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
