  5. /CSD25304W1015
CSD25304W1015 thumbnail 1
Texas Instruments

CSD25304W1015

Category
Transistors
Manufacturer
Texas InstrumentsDetails
Datasheet
Description
-20-V, P channel NexFET™ power MOSFET single WLP 1 mm x 1.5 mm, 32.5 mOhm
Similar Products
—
Quality Control
Authentic & Traceable
Shipping (In-stock)
1-3 business days
Quote Response
Within 24 Hours
Stock Status6690
QuantityCSD25304W1015
Country

Get Tiered Pricing (Submit RFQ)

Specification
Product Details
Key Features
Documentation
TypeDescriptionTypeDescription
VDS (V)-20VGS (V)-8
TypeP-channelConfigurationSingle
Rds(on) at VGS=4.5 V (max) (mΩ)32.5Rds(on) at VGS=2.5 V (max) (mΩ)45.5
VGSTH typ (typ) (V)-0.8QG (typ) (nC)3.3
QGD (typ) (nC)0.5QGS (typ) (nC)0.7
ID - silicon limited at TC=25°C (A)3Logic levelYes
RatingCatalogOperating temperature range (°C)-55 to 150
PackageDSBGA (YZC)Pins6
Size2.1875 mm² (— mm × — mm)
