| Type | Description | ||
|---|---|---|---|
| Rating | Catalog | Number of series cells | 1, 2, 3 |
| Cell chemistry | Li-Ion/Li-Polymer | Charge current (max) (A) | 4 |
| Features | BAT temp thermistor monitoring (JEITA profile), BAT temp thermistor monitoring (hot/cold profile), IC thermal regulation, IINDPM (Input current limit), Input OVP, Power Path | Vin (min) (V) | 4.5 |
| Vin (max) (V) | 17 | Absolute max Vin (max) (V) | 20 |
| Control topology | Switch-Mode Buck | Battery charge voltage (min) (V) | 2.1 |
| Battery charge voltage (max) (V) | 15.5 | Control interface | Standalone (RC-Settable) |
| Operating temperature range (°C) | -40 to 85 | Package | VQFN (RGY) |
| Pins | 24 | Size | 19.25 mm² (5.5 mm × 3.5 mm) |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
BQ24171 is an authentic electronic component manufactured by Texas Instruments, categorized under Power Management ICs. It is supplied in the standard VQFN (RGY) package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official BQ24171 datasheet above.
Electronic component spot-market pricing for BQ24171 fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for BQ24171 depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
