  5. /STGFW80V60F
STGFW80V60F thumbnail 1
STMicroelectronics

STGFW80V60F

Category
Discrete & Power Modules
Manufacturer
STMicroelectronicsDetails
Datasheet
—
Description
79W 120A 600V FS (Field Stop) TO-3P-3 IGBT Transistors / Modules ROHS
Similar Products
—
Quality Control
Authentic & Traceable
Shipping (In-stock)
1-3 business days
Quote Response
Within 24 Hours
Stock Status5290
QuantitySTGFW80V60F
Country

Get Tiered Pricing (Submit RFQ)

Specification
TypeDescriptionTypeDescription
PackageTO-3P-3Td(off)220ns
Pd - Power Dissipation79WTd(on)60ns
Current - Collector(Ic)120ACollector-Emitter Breakdown Voltage (Vces)600V
IGBT TypeFS (Field Stop)Gate-Emitter Threshold Voltage (Vge(th)@Ic)2.3V@15V,80A
Gate Charge(Qg)448nCOperating Temperature-55℃~+175℃@(Tj)
Switching Energy(Eoff)1mJTurn-On Energy (Eon)1.8mJ
CNHTS8541600000USHTS8541600080
TARIC8541600000CAHTS8541600010
BRHTS85416010INHTS85416000
MXHTS8541.60.01
