| Type | Description | ||
|---|---|---|---|
| Series | PIC® 16C | Packaging | Tube |
| Part Status | Obsolete | Core Processor | PIC |
| Core Size | 8-Bit | Mounting Type | Through Hole |
| Number of I/O | 11 | Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | Internal | Package / Case | 14-CDIP (0.300", 7.62mm) Window |
| Peripherals | POR, WDT | Program Memory Size | 1.5KB (1K x 12) |
| Program Memory Type | EPROM, UV | RAM Size | 72 x 8 |
| Speed | 20MHz | Supplier Device Package | 14-CDIP |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V | ExportControlClassNumber | EAR99 |
| HtsusCode | 8542.31.0015 | MoistureSensitivityLevel | 1 (Unlimited) |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
PIC16C505/JW is an authentic electronic component manufactured by Microchip, categorized under Interface ICs. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official PIC16C505/JW datasheet above.
Electronic component spot-market pricing for PIC16C505/JW fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for PIC16C505/JW depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
