| Type | Description | ||
|---|---|---|---|
| RoHS Status | RoHS Compliant | Part Life Cycle Code | Not Recommended |
| Part Package Code | 40-LFCSP-6X6X0.75 | Package Description | 6 X 6 MM, LEAD FREE, TQFN-40 |
| Pin Count | 40 | Manufacturer Package Code | 40-LFCSP-6X6X0.75 |
| Reach Compliance Code | compliant | Date Of Intro | 2008-05-23 |
| Additional Feature | ALSO OPERATES IN ADJUSTABLE MODE FROM 0.7 TO 5.5V; ALSO OPERATES IN CURRENT MODE | Analog IC - Other Type | SWITCHING REGULATOR |
| Control Mode | VOLTAGE-MODE | Control Technique | PULSE WIDTH MODULATION |
| Input Voltage-Max | 20 V | Input Voltage-Min | 4.5 V |
| Input Voltage-Nom | 12 V | JESD-30 Code | S-XQCC-N40 |
| JESD-609 Code | e3 | Length | 6 mm |
| Moisture Sensitivity Level | 3 | Number of Functions | 1 |
YG GROUP (YUGUANG INTERNATIONAL(HK)CO.,LTD) supports reliable sourcing through quality controls and compliance documentation. Please confirm product requirements, applicable certifications and supporting documents before ordering.
MAX8686ETL+ is an authentic electronic component manufactured by Analog Devices, categorized under DC/DC Converters. It is supplied in the standard manufacturer-specified package footprint, providing industry-standard mechanical dimensions and terminal configurations for board-level assembly. Full pinout configurations, physical footprint drawings, and rated operating tolerances are documented in the official MAX8686ETL+ datasheet above.
Electronic component spot-market pricing for MAX8686ETL+ fluctuates based on real-time global availability, production date codes, minimum order quantities (MOQ), and packaging formats (e.g., Reel, Tube, Tray). Using an RFQ ensures you receive accurate, real-time volume pricing tied to verified, traceable inventory rather than stale catalog estimates.
Lead times for MAX8686ETL+ depend on whether stock is dispatched from our central hub or regional franchise partners. Ready-to-ship inventory typically leaves the warehouse within 1–3 business days following quality inspection, while factory-direct or back-ordered allocations are confirmed with an estimated ship date upon RFQ reply.
